EMC-KEL-U | Split EMC cable entry frames
for shielding cables with connectors
The EMC cable entry frames EMC-KEL-U are based on the KEL-U and KEL-E. Due to a conductive surface, disturbances in the cable shields on the control cabinet can be easily dissipated. Field bound disturbances are derived by the metallisation.
The cable entry system is easy to install. Cable grommets are placed into compartments and are securely fixed to the frame during assembly.
The EMC-KEL-U frames match exactly the cut-out dimensions for 16- and 24-pin standard industrial connectors. Either a cut-out of 36 mm or 46 mm in height can be chosen depending on the cables being routed.
The single-row versions EMC-KEL-E are particularly suited for flat connectors. The small frames are ideal for applications with limited space.
Between the EMC-KEL-U and the metal wall a conductive flat gasket (included) is mounted. The flange surface on the metal wall must be free of paint!
Part No.
99401
Specifications
Flame class
UL94-HB
Operating temperature
-40 C° to 140 C°
Properties
vibration proof
Advantages and benefits
Both conducted and field-bound disturbances can be reliably diverted
Scratch-resistant surface
Contacting the cable shield over 360°
EMC grommets made entirely from conductive elastomer
High cable density, wide variety of grommets
Very good dissipation values
Very good shielding effect with regard to EMC tightness
The EMC cable entry frames EMC-KEL-U are based on the KEL-U and KEL-E. Due to a conductive surface, disturbances in the cable shields on the control cabinet can be easily dissipated. Field bound disturbances are derived by the metallisation.
The cable entry system is easy to install. Cable grommets are placed into compartments and are securely fixed to the frame during assembly.
The EMC-KEL-U frames match exactly the cut-out dimensions for 16- and 24-pin standard industrial connectors. Either a cut-out of 36 mm or 46 mm in height can be chosen depending on the cables being routed.
The single-row versions EMC-KEL-E are particularly suited for flat connectors. The small frames are ideal for applications with limited space.
Between the EMC-KEL-U and the metal wall a conductive flat gasket (included) is mounted. The flange surface on the metal wall must be free of paint!
